Refrigerated Dryers

Available from 15-1500 CFM

Easy to install and operate, just like our air compressors.

Features

Patented ultra-compact aluminum heat exchanger with flow mixing
chamber for uniform evaporator entry
Low pressure drop
NPT connections
Timed electric auto drain
Electronic board with double sensor system monitoring dew point
and condensing pressure
Air/air pre-cool and post-heat stage, reducing energy use
and preventing outlet pipe sweating
Demister separation with automatic condensate drain
By-pass valve for refrigerant and temperature regulation
Control panel displays dew point, operating mode,
drain management, and alarms
Oversize components and easy maintenance access
Eco-friendly refrigerant gases and recyclable materials
Rated to ISO 7183 standard conditions: 100°F ambient,
100°F inlet, 100 psig
Class 5 dew point, 45°F (ISO 8573-1:2010)
UL / CSA certified

350–1500 CFM Models

Class 4 dew point, 38°F (ISO 8573-1:2010)
Thermal protection switch
Hard alarms for high and low temperature
Dew point held stable under any
operating condition
Rated for ambient temperatures to 120°F

Downloads

Model	CFM	Voltage	Inlet/Outlet Connections	L×W×H (Inches)	Weight (lbs)
RD15AT	15	115/1/60	3/4"	12 × 14.7 × 17.3	40
RD20AT	20	115/1/60	3/4"	12 × 14.7 × 17.3	40
RD35AT	35	115/1/60	3/4"	12 × 14.7 × 17.3	42
RD50AT	50	115/1/60	3/4"	13.6 × 16.1 × 18.9	53
RD75AT	75	115/1/60	1"	15.7 × 18.2 × 21.3	60
RD100AT	100	115/1/60	1"	15.7 × 18.2 × 21.3	66
RD125AT	125	115/1/60	1"	15.7 × 18.2 × 21.3	88
RD150AT	150	115/1/60	1"	15.7 × 18.2 × 21.3	90
RD175AT	175	115/1/60	1 1/2"	21.2 × 21.2 × 26.9	121
RD220AT	220	230/1/60	1 1/2"	20.7 × 24.7 × 44.2	159
RD300AT	300	230/1/60	1 1/2"	20.7 × 24.7 × 44.2	172
RD350-AT	350	230/1/60	2"	26.6 × 28.1 × 56.1	172
RD400-AT	400	230/1/60	2"	26.6 × 28.1 × 56.1	275
RD500-AT	500	460/3/60	2"	26.6 × 28.1 × 56.1	308
RD600-AT	600	460/3/60	2 1/2"	26.6 × 28.1 × 56.1	330
RD800-AT	800	460/3/60	2 1/2"	26.6 × 28.1 × 56.1	341
RD1000-AT	1000	460/3/60	3"	25.9 × 53.3 × 62.1	550
RD1500-AT	1500	460/3/60	3"	25.9 × 53.3 × 62.1	660
